KitchenAid Freezer Control Panel Parts, For Model KSSS42MDX05, Illus. Part No. No. DESCRIPTION

Models: KSSS42MDX05

1 24

Download 24 pages 60.42 Kb

Page 8

Image 8

FREEZER CONTROL PANEL PARTS

For Model: KSSS42MDX05

Illus. Part

No. No. DESCRIPTION

11113626 Control Panel

22003308 Inlay, Control Panel

31113466 Thermostat & Barrier Assembly

4488974 Screw (2)

51115373 Switch, Rocker Arm

61113134 Seal, Control Panel

8489260 Screw (3)

92000153 Hole Plug (3)

101113768 Shield, Control Panel

111112613 Socket, Light

12486194 Screw

13548049 Light Bulb

142001973 Channel, Wiring

162182112 Knob, Thermostat

171115375 Clip, Wiring

4394682

Page 8

Image 8

KitchenAid manual Freezer Control Panel Parts, For Model KSSS42MDX05, Illus. Part No. No. DESCRIPTION
