Specifications & Capacities

Food Plot Seeder



FPS48





Description

Specification





Hitch Type

Pull type with optional 2" ball hitch or clevis hitch





Base Unit Weight

370 lbs.





Base Unit Weight with

510 lbs.

Spin Spreader and Packer







Disc Cutting Width

40" to 50"





Minimum ATV Size

350 cc





Minimum Tractor/vehicle Size

17 hp





Height

52"





Length

104"





Width

54"





Weight Load on Each Disc

46 lbs.





Number of Disc Blades

8





Disc Blade Size & Type

16" Notched





Blade Spacing

7 1/2"





Transport / Gauging Tires

13" Diameter 4 ply tubeless





Bearing Hanger

3/8" Plate





Bearing Type, 2 per Gang

Self Aligning, Sealed Bearing





Gang Tube

3" x 2"





Gang Axle

1" Square high carbon steel





Disc Angle

Front Gang: 0, 7, 14 & 21 degrees



Rear Gang: 0, 7, 14 & 21 degrees





Frame Construction

2" x 2" Square tubular design





Lifting Device

Ratchet Jack or Linear Actuator, 12 volt





Rear Axle pivot Type

Greasable





Rear Roller Bearing

Greasable











Optional Spin Spreader and Packer





Packer Roller Width

40 7/16"





Spreading Device

Spin Spreader, 12V





Spreader Hopper Loading Height

42" off ground





Spin Spreader Volume/Capacity

2 cu. ft. (15 gallons) (100 lbs. Maximum capacity weight)





Spin Spreader Deflector

Diverts seed to smaller spreading width. Seed rate charts calculated at 48"





Small Seed Restrictor

Restricts small seed for smaller distribution levels.









Designs, specifications, features and information are subject to change without notice.

21

322-118S

1/19/06

Page 1
Image 1
Land Pride FPS48 specifications Specifications & Capacities Food Plot Seeder, Description Specification

FPS48 specifications

The Land Pride FPS48 is a highly efficient, versatile 48-inch flail mower designed for compact utility tractors and smaller agricultural applications. Known for its robust construction and advanced technology, the FPS48 is an excellent choice for maintaining lawns, pastures, and other grassy areas. Its innovative design and performance capabilities make it a favorite among landscaping professionals, farmers, and property owners.

One of the main features of the Land Pride FPS48 is its heavy-duty steel frame, which provides exceptional durability and stability while operating on rough terrain. The mower's low-profile design allows for a lower center of gravity, enhancing stability and preventing tipping during use. This design is particularly beneficial when mowing on slopes or uneven surfaces.

The FPS48 is equipped with a flail blade system that delivers a superior cutting performance compared to traditional rotary mowers. The flail blades are more efficient at cutting thicker grass and brush, allowing operators to tackle a variety of vegetation with ease. The blades are designed to pulverize clippings, which promotes a healthier lawn by returning nutrients to the soil rather than leaving behind visible debris.

Another key characteristic of the FPS48 is its adjustable cutting height. Operators can easily modify the mower’s height from 1 to 4 inches, allowing for greater flexibility in mowing different types of grass and maintaining various landscapes. This adjustability also ensures that the mower can effectively handle rough patches, tall weeds, and low-growing grass with precision.

The mower is also designed with user safety in mind. Equipped with a mower guard and safety features such as a PTO shaft shield, the FPS48 minimizes the risk of accidents during operation. Additionally, its quick-hitch compatibility allows for fast attachment and detachment from tractors, ensuring that users spend less time on setup and more time on the job.

The Land Pride FPS48 combines advanced engineering with top-notch performance, providing an ideal solution for those looking to maintain their lawns and landscapes effectively. With its robust construction, versatile capabilities, and focus on user safety, this flail mower stands out as a reliable choice for both residential and commercial applications. Whether for land maintenance or professional use, the FPS48 is designed to meet the tough challenges of grass cutting while delivering exceptional results.
