LG Design
This range is comprised with an abundance of stainless steel for a striking presentation. The stainless steel backsplash, control panel, cooktop surface, door and handle all add to the contemporary and modern look.
Spacious 5.6 cu.ft. Capacity
Cooking for a full house is no longer a tight squeeze with LG's 5.6 cu.ft. electric range. Not only can you cook a large turkey, but you'll have room for biscuits and a casserole too. The elegant blue interior complements the exterior styling and gives your range a more premium look.
Dual Convection System
Twin Fan and dual heating elements delivers a 30% faster preheat time* and insures even heat distribution for uniform baking.
IntuiTouch™
Control System
Easy to use and easy to clean, the IntuiTouch™ Control System makes operating your range a snap. The left side of the panel mirrors the cooktop elements, while the right side controls the oven functions.
Warming Drawer
While preparing the rest of your meal, the warming drawer can be used to keep already cooked foods at serving temperature. With 5 heat settings, you can warm everything from rolls to porkchops so
they can be served hot and fresh.
*Based on testing results comparing standard LG convection range to the dual convection range (325°F) mode.
Installation Reference
(see chart at right for measurements)
A
C
B
D
LG ELECTRONICS INC.
1000 Sylvan Ave., Englewood Cliffs, NJ 07632
800.243.0000 | LGusa.com |
E L E C T R I C R A N G E | ||
| LRE30757 |
|
Type | Freestanding Electric | |
Capacity (cu.ft.) | 5.6 |
|
C O N T RO L S |
|
|
Oven / Cooktop | Keypad |
|
Layout | IntuiTouch™ Control System |
|
Display | IntuiScroll™ Scrolling Display | |
Electronic Clock & Timer |
|
|
Control Lock Function | (Except Kitchen Timer, Clock Set, Oven Light) | |
| ||
Audible Preheat Signal |
|
|
Special Functions (7 Options) | Clock (12 hr, 24 hr), | |
| Temperature Unit of Measure (F/C), | |
| Beeper Volume (High, Low, Mute), | |
| GoCook™ Smart Oven Light On/Off, | |
| Convection On/Off, Thermostat Adjustment, | |
| Language: English or Spanish | |
COOKTOP |
|
|
Ceramic |
|
|
No. of Radiant Elements | 5 |
|
No. of Radiant Heat Settings | 25 |
|
Warming Zone |
|
|
ELEMENT SIZE AND WATTAGE |
|
|
Left Rear and Right Rear | 6"/ 1200W |
|
Center Rear (Warming Zone) | 7"/ 100W |
|
Left Front | 9"/ 2500W |
|
Right Front | 9"/12" / 1700W/2700W | |
OVEN |
|
|
|
| |
Variable Cleaning Time (2 hr, 3 hr & 4 hr) |
|
|
Variable Broil (High, Low) |
|
|
Broil Element | 6 Pass / 4000W |
|
Bake Element | Hidden Bake (6 Pass / 3400W) | |
Convection Conversion |
|
|
Convection System | Dual Convection | |
Convection Bake |
|
|
Convection Roast |
|
|
Convection Element | 2 (700W each) | |
No. of Rack Positions | 7 |
|
No. of Racks | 3 (2 | |
WideView™ Window |
|
|
Automatic | After 12 Hours |
|
Interior Oven Light (Auto/Manual adjustment) | 1 Incandescent | |
GoCook™ Smart Oven Light |
|
|
Delay Bake / Delay Clean |
|
|
Proofing |
|
|
Cook & Warm |
|
|
Favorites | 3 (Bread, Meat, Chicken) | |
DRAWER |
|
|
Type | Warming |
|
Heating Element | 600W |
|
Temperature Settings | 5 (131°F, 149°F, 167°F, 185°F, 203°F) | |
Warming Rack |
|
|
Capacity / Dimensions (WxHxD) | 1.19 (cu.ft.) / 23" x 5" x 17 3/4" | |
SAFETY FEATURES |
|
|
Door Lock |
|
|
MATERIALS/FINISHES |
|
|
Available Colors | White (SW), Black (SB), Stainless Steel (ST) |
|
Handles | SW (White Finish), SB (Black Finish), | |
| ST (Stainless Steel) | |
POWER SOURCE |
|
|
Requirements | 120/240 VAC, 120/208 VAC | |
DIMENSIONS |
|
|
A: Width | 29 7/8" |
|
B: Height (to top of cooktop) | 36" |
|
C: Height (to top of backguard) | 47 5/8" |
|
D: Depth (including door) | 25 11/16" |
|
Depth (including handle) | 28" |
|
Oven Cavity (WxHxD) | 24 1/2" x 20 1/4" x 19 3/8" |
|
WideView™ Window (WxH) | 20 1/4" x 12 1/4" |
|
Net Weight / Shipping Weight | 181 lbs / 205 lbs |
|
Package Dimensions (WxHxD) | 33" x 30" x 51" |
|
Stuffing Quantity (53 ft. High) | 108 units | |
ACCESSORIES |
|
|
Broiler Pan |
|
|
WARRANTY |
|
|
| 1 Year Parts and Labor (In Home Service) | |
| 5 Years Limited on Cooktop | |
| and Radiant Surface Units | |
UPC CODE |
|
|
LRE30757SW | 048231 316057 |
|
LRE30757SB | 048231 316064 |
|
LRE30757ST | 048231 316040 |
|
Design and specifications are subject to change without notice. ©2008 LG Electronics U.S.A., Inc., Englewood Cliffs, NJ
All Rights Reserved. LG Design and Life's Good are trademarks of LG Electronics Inc. All other trademarks are property of their respective owners.
Printed in March 2008
