READ AND UNDERSTAND THESE INSTRUCTIONS	INSTRUCTION SHEET NO.
BEFORE INSTALLING LUMINAIRE.		IS:1101F
installation. To prevent electric shock, turn off electricity at main power supply before proceeding.
This luminaire is intended for installation in accordance with the National Electrical Code and local regulations.
To assure full compliance with local codes and regulations, check with your local electrical inspector before
Retain these instructions for maintenance reference.
		D1007	Page 1 of 3

INSTALLATION PROCEDURE FOR:

Lytecaster® 1101F, 1001F and 2001F Series Frame-In Kits

CAUTION: (RISK OF FIRE) THIS IS A NON-IC RATED FRAME-IN KIT.

DO NOT INSTALL INSULATION ABOVE OR WITHIN 3 INCHES (76mm) OF ANY PART OF LUMINAIRE.

CAUTION: USE ONLY WITH REFLECTOR TRIMS PROVIDED BY LIGHTOLIER. USE OF OTHER MANUFACTURER’S TRIMS

MAY VOID THE UNDERWRITERS LABORATORIES LISTING AND COULD CONSTITUTE A FIRE HAZARD.

CAUTION: BEFORE INSTALLING FRAME-IN KIT AND REFLECTOR TRIM, READ ALL MARKINGS ON FRAME-IN KIT AND

REFLECTOR TO DETERMINE LAMP WATTAGE AND TYPE APPLICABLE FOR YOUR INSTALLATION.

INSTALLATION INSTRUCTIONS FOR GRID CEILING APPLICATIONS
1 PREPARATION: Cut appropriately sized hole in Ceiling Tile (by	APERTURE HOLE SIZE
others) at the position desired and place Ceiling Tile in Grid (by	1101F SERIES	6-15/16” (176mm) DIA.
others) (Figure A). Loosen Wing Nuts on Frame Clamps enough to	1001F SERIES	5-1/4” (134mm) DIA.
allow free movement of Mounting Bars (Figure B).
	2001F SERIES	3-15/16” (100mm) DIA.

2POSITION LUMINAIRE FRAME: Place Luminaire Frame on top of Ceiling Tile and center the frame aperture on the Ceiling Tile hole cut in Step 1 so that the aperture wall extends into the Ceiling Tile. Orient the Luminaire Frame to align with the grid (Figure C). Grasp the T-Bar Clips on each end, one in each hand, lift the clips to the top of the adjustment slots in the End bracket, extend the End brackets to contact the Ceiling Grid, and drop each T-Bar Clip over the Grid (Figure D).

NOTE: When the Luminaire Frame is to be used with Wall Wash Trims make sure to orient the Luminaire Frame side indicated by a label on the frame towards the wall to be illuminated.

3CLAMP TO GRID and LOCK LUMINAIRE FRAME: Making certain that the Luminaire Frame is still centered on the Ceiling Tile, tighten the T-Bar Clip Wing Nuts to attach the frame to the Ceiling Grid (Figure E). Retighten the Wing Nuts on the Frame Lock Clamps after the frame is positioned satisfactorily and is locked to the Ceiling Grid.

	Figure B	Figure D	Figure F
*	BALLAST REPLACEMENT: Ballast replacement must be performed by a “qualified electrician”. TURN OFF
	POWER. Remove reflector trim from luminaire. Remove j-box cover to which the ballast is mounted by lifting the
	spring. For LC models remove two battery nuts. Remove ballast assembly through the ceiling hole. Disconnect all
	input wiring to the ballast. Release all wires from ballast wire connectors by inserting small blade tool, with insulated
	handle, into wire release slots (Figure F). Remove ballast from j-box door and replace with new ballast. Rewire and
	reassemble.
*	REFLECTOR TRIM INSTALLATION: See separate Trim Instruction Sheet for installation procedure.
