Lytespan® Track Lighting System  22MW6































































































































































Page 1 of 2































AlcyonMini Wall Washer MR16





2

3





5"







(127mm)



1 1/2"



4 1/4"



(38mm)

1



(108mm)





15/16"







(24mm)





1/2"



3 13/16"



(13mm)



(97mm)





4 3/4"







(120mm)

9









8

211/16"

(68mm)

3 3/4" (96mm)

Ordering Information

4

5

6

7

Catalog No.

Finish

Mounting

Lamps

22MW6WH

Matte White

All Lytespan Track Systems.

MR16 Lamp with out Integral lens, 50W Max

22MW6BK

Matte Black

Does not mount on ProSpec Track.

MR16 Lamp with integral lens, 37W Max

22MW6AL

Metallic Aluminum



Recommended Lamp Beam Spread: 25° - 40°







Optimal Lamp Beam Spread: 36°









Features

1.Transformer: Class two electronic transformer for 12v halogen lamps

2.Track Attachment Fitting: Molded polycarbonate; rotates into track

3.Brass Contact: Extends for connection to second circuit (Advent Lytespan track only)

4.Horizontal Pivot: Wireless stem profile with infinite horizontal rotation

5.Vertical Pivot: 0-90° vertical adjustment

6.Socket: Bi-pin multipoint contact low voltage halogen socket

7.Housing: Die cast aluminum

8.Front Cartridge: Hinged and captive.

9.Beam Elongator Lens: Fixed to ensure proper alignment. Meets UL standards for use with unshielded lamps

Finish

All Painted finishes are baked enamel.

Dimming

Use only dimmers specifically designed for use with electronic transformers. Low voltage fixtures may produce audible sound when dimmed.

Accessories

Accessory Holder: None

Accessories: None

Lens:None

Louver:None

Snoot Accessory: None

Labels

UL, cUL

Job Information

Type:





Job Name:

Cat. No.:

Lamp(s):

Notes:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish. www.lightolier.com © 2008 Philips Group • E0808

Lightolier is a Philips group brand

Page 1
