Specification Decorative BowShield™ 40831

Page 1 of 2 Wall Mounted Incandescent ADA Compliant

5

17 1/8"

1

2

7 15/16"

4

3

7

4 1/2"

To Outlet

Box Center

4"

Complete Fixture consists of Lightshield and Backplate Assembly. Order each separately. Lightshield Ordering Information

Pattern/Description/Color

No.

40872

40866

40863

Rolled “Rain” pattern texture, Silk-screened White/Clear fused in place.

Three Dimensional “Squares”

White/Clear Silk-screened

Pattern

“Ceramic White” Silk-screened and Sandblasted

Backplate Assembly Ordering Information

Cat. No. Lamps Finish

40831

40832

2x60W T-10 Incandescent 2x60W T-10 Incandescent

Satin Brass Satin Nickel

Features

1.Diffuser Holder: Die-cast zinc alloy. Satin brass or satin nickel finish with clear lacquer.

2.Diffuser Support Peg: Turned brass. Satin brass or satin nickel finish with clear lacquer.

3.Backplate: 20 ga. (.036”) Die-formed steel, gloss white finish.

4.Socket: Medium Base, Porcelain, Nickel Plate Screw Shell.

5.Lamps: T-10, Medium Base, by others.

6.Diffuser: 6mm thick (Max.) Glass. See chart above for option.

7.Screw: Nylon. 8-32. To secure Diffuser.

Labels

cULus listed suitable for damp locations.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s): Notes:

Lightolier a Genlyte companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2005 Genlyte Group LLC • C0905
