READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local
regulations. To assure full compliance with local codes and regulations, check with your local electrical Inspector before installation, To prevent electrical shock, turnoff electricity at fuse box before proceeding,
Retain these instructions for maintenance reference.
INSTALLATION INSTRUCTIONS
INSTRUCTION SHEET NO,
IS:6020
A1103R1292 | Page 1 of 4 |
FOR BASIC LYTESPAN@TRACK LIGHTING INDIVIDUAL AND JOINER TRACK UNITS
Basic Lytespan track lighting is designed to support and energize LytespotsS which can be attached anywhere along the track. It is a
IMPORTANT SAFETY INSTRUCTIONS
WHEN INSTALLING OR USING THIS TRACK SYSTEM, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
~READ ALL INSTRUCTIONS
“THIS TRACK SYSTEM IS INTENDED FOR INSTALLATION IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND LOCAL OR FEDERAL CODE SPECIFICATIONS.
. DO NOT INSTALL THIS TRACK IN WET OR DAMP LOCATIONS.
~DO NOT INSTALL ANY PART OF THE TRACK SYSTEM LESS THAN 5 FEET ABOVE THE FLOOR,
oDO NOT INSTALL ANY FIXTURE ASSEMBLY CLOSER THAN 6 INCHES FROM ANY CURTAIN, OR SIMILAR COMBUSTIBLE MATERIAL.
‘TO PREVENT ELECTRICAL SHOCK, TURN OFF ELECTRICITY AT FUSE BOX BEFORE INSTALLING THE TRACK OR ADDING TO OR CHANGING THE CONFIGURATION OF THE TRACK.
oINSTRUCTIONS FOR GROUNDING PER INSTRUCTION SHEET OF THE
~USE #12 OR 14 GA. AWG SOLID WIRE ONLY (NOT STRANDED WIRE) FOR SUPPLY TO TRACK.
~OBSERVE POLARITY, (NEUTRAL) WHITE SUPPLY LEAD TO CONTACT MARKED “NEUT” IN LIVE END.
“DO NOT AllEMPT TO ENERGIZE ANYTHING OTHER THAN TRACK LIGHTING FIXTURES ON THE TRACK. TO REDUCE THE RISK OF FIRE AND ELECTRICAL SHOCK, DO NOT AllEMPT TO CONNECT POWER TOOLS, EXTENSION CORDS, APPLIANCES AND THE LIKE TO THE TRACK.
