Lightolier 6284 specifications Lytespan Track Lighting System, Page 1 of, Par Ring Lytespot, Type

Lytespan® Track Lighting System 6284

Page 1 of 2

LYTESPAN ATTACHMENT FITTING: Molded polycarbonate. Integral color. Fitter twists onto track and locks on.

PUSH TAB: Molded poly- carbonate. Detaches unit.

YOKE: .093” steel.

TRUNION MOUNTING: Tensioned with Internal spring washer and vibration- resistant nut

HOUSING: .040” aluminum

Par Ring Lytespot

MOVABLE BRASS CONTACT: Extends for connection to 2nd circuit in Advent Lytespan Track.

POLARITY KEYWAY

PIVOT MOUNTING

Tensioned; 350° stop.

SOCKET COVER impact extruded aluminum.

Catalog No.	Finishes	Mounting	Lamps	Accessories
6284	Matte White	All Lytespan Track	55W-150W PAR-38	4 3/4” Dia Series Color Filters, Heat
6285	Matte Black	Systems	(Cool Beam Also)	Filter, Spread Lens, Louver and Wall
			45W-250W PAR-38	Washer Accessory (see Lightolier
			(Tungsten-Halogen)	Specification Sheets AF, AF2AS,
				AL4CC, 7650 and 6280

General Description

Minimal, functional form with cleanly detailed yoke and ring-shaped Iampholder, uses 250W PAR-38 lamp for maximum compactness. Permanently-tensioned trunion mounting allows Lytespot to remain fixed at any angle. Unit adjusts horizontally up to 350°, vertically up to 90°. Regressed spring clips retain filters, spread lens, louver, adjustable “barn doors” and wall washer accessory.

Patents

U.S. Patent No. 3,498,518. Foreign Patents granted

Finish

All painted finishes baked enamel.

Electrical

Porcelain socket, medium base, nickel plated screw shell. No. 18 braided SF-1 leads.

Labels

UL; C.S.A.; I.B.E.W.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s): Notes:

Lightolier a Genlyte Thomas Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
