Lightolier CS7142 specifications Page 1 of, Job Information, Type, Complete Fixture Ceiling Mount

	Calculite® Compact Fluorescent Surface Cylinder CS7142
Page 1 of 2	7 3/8" Aperture Triple Tube (4-Pin) Ceiling & Wall Mount

3

4

5

7 3/8"

(188 mm)

7 7/8"

(200 mm)

6

2

121/8" (308 mm)

10

9

8

7

1

8 3/8"

(213 mm)

3/8" (10 mm)

373/4" (959 mm)

FACSA36 (Stem Kit)

			CW7142 (Wall Mount)
Complete Fixture Ceiling Mount			Lamp
CS7142VUCCL	Comfort Clear™ Reflector	120V - 277V	26, 32 or 42W Triple Tube
	White Housing		4-Pin (Amalgam)
Complete Fixture Wall Mount			Lamp
CW7142VUCCL	Comfort Clear™ Reflector		26, 32 or 42W Triple Tube
	White Housing	120V - 277V	4-Pin (Amalgam)

Features

1.Reflector: 16 ga. Alzak® aluminum, 50° visual cutoff to lamp and lamp image, medium distribution. Comfort Clear™ low iridescence finish.

2.Housing: One piece 16 ga. spun aluminum with returned bottom edge to seat reflector; no visible hardware. Matte white baked enamel finish.

3.Ballast: Mounted on support bracket, can be easily removed for service.

4.Socket Bracket: Snaps onto reflector neck to assure consistently correct optical alignment.

5.Retaining Springs: Precision-tooled steel friction springs secure reflector to mounting frame for quick, tool-less installation.

6.Stem Kit: Cat. No. FA CSA36: Provided with 1/2" dia. stem and 4 1/2" dia. canopy. Self-aligning swivel provides maximum 40° vertical adjustment. Installs over 4" octagonal outlet box. Stem can be cut to length on site. Matte white baked enamel finish.

7.Crossbar: Installs over 3" or 4" octagonal or rectangular outlet box.

8.Cleat: Cast aluminum; allows mounting to mullion or post without backplate.

9.Backplate: Die-cast aluminum; 6 1/4" high by 4" wide; matte white.

10.Bracket: Extruded aluminum; matte white finish. Secured to cleat by set screws.

Electrical

Note: For ballast electrical data and latest lamp/ballast compatibility refer to “Ballast” specification sheet for complete electrical data.

UL listed for 90°C supply conductors.

Options and Accessories

Other Reflector and Housing Finishes Consult factory

Fuse (Slow Blow) Add Suffix F

Labels

UL listed for damp locations, I.B.E.W.

Alzak® is a registered trademark of ALCOA.

US Patent Pending.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Companywww.lightolier.com 631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710 We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
