Memorex quick start Quick Start Guide, RF5700 Keyboard & Mouse

Once you insert the installation CD, the installation should begin automatically. Select installation options for the RF5700 devices and follow the on-screen instructions.

If the installation does not begin automatically, you may need to do the following:

a)Click on the Start menu, then Click on the Run button.

b)Browse to the drive where the Installation CD is located.

c)Select the Autorun.exe file, then click on the Open button.

d)Click on OK to start the installation manually.

e)Select installation options for the RF5700 devices and follow the onscreen instructions.

For more information on how to use the RF5700 Keyboard and Mouse, please read the User's Guide. The User's Guide can be found on the included CD, under the folder named “Rf5700”, in the keyboard-driver folder. You can also find the User's guide and other supporting documents on the Memorex Website. Please visit www.memorex.com/products and follow the links to the Keyboard product listings for specific product manuals and guides.

If you need any additional help in connecting, synchronizing or installing the RF5700, please feel free to contact Memorex's technical support.

Email techsupport@memorex.com with your questions, or visit us online at www.memorex.com for our Frequently Asked Questions. Phone support is available at (310) 891-1680 from the hours of 9:00am to 6:00pm, PST. M-F.

© 2003 Memorex Products, Inc.

Quick Start Guide

RF5700 KEYBOARD & MOUSE

Before beginning the installation of your new RF5700 Keyboard and Mouse, please make sure that your computer is powered OFF.

CONNECTING YOUR NEW RF5700 KEYBOARD AND MOUSE

1)Remove the keyboard, mouse, and receiver from the box.

2)Make sure that all 3 pieces are on the same channel-either channel 1 or 2 (The Channel Switch is on the bottom of each device. The mouse channel switch is located inside the battery compartment). Either channel is okay to use, but all 3 of the devices have to be on the same channel for proper synchronization. (Fig 1, Fig 2, Fig 3, and Fig 4)

Channel Switch

Mouse Battery Compartment

and Switch (Fig2)

Keyboard Bottom (Fig 1)

Receiver Bottom (Fig 4)

Receiver Channel Selector (Fig 3)

3)Insert your supplied batteries into the keyboard and mouse according to the diagrams on the devices. (Fig 1 and Fig 2) To ensure proper battery installation, please refer to the battery direction layouts located in the battery compartments of your keyboard and mouse.

4)Unplug your current keyboard connector from the computer.

5)Plug the purple PS/2 connector on the receiver into the keyboard port on your computer. (Fig 5)

.

Keyboard Connector from Receiver (Purple)

(Fig 5)
