Technical data sheet for

TARGET TOP GAS / ELECTRIC STATIC OVEN RANGE 900mm

RN8110GE

Heavy-duty cast iron top with removable centre ring

Matched modular height machined top for seamless work surface

High output dual ring cast iron burner GN 2/1 6.5kW electric static oven Drop down door

Stainless steel exterior Easy clean

Easy service Fully modular

Overall Construction

•Galvanized steel chassis

•Welded hob surround with 1.5mm 304 stainless steel bull nose

•Splashback and hob sides 1.2mm 304 stainless steel

•Front panels and oven sides 0.9mm 304 stainless steel

•150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with adjustable feet

Target top

•3 piece heavy-duty cast iron top with fully machined surface

•Top plates and removable centre with integral spill protection design

•Cast top reinforced with integral heat fins for heat zone definition

•45MJ dual ring cast iron burner with single control

•Full pilot and flame failure protection

•50mm thick refractory brick lined burner box for high heat retention

•2 vitreous enamelled spill trays

•Supplied with heavy-duty centre casting removal tool

Oven

•Fully welded and vitreous enamelled oven liner

•GN 2/1 capacity with 4 position racking

•Heavy-duty easy remove heavy wire chrome rack supports

•Cast iron even heat oven sole plate

•6.5kW heating elements

•Welded frame drop down door with heavy-duty spring hinge system

•0.9mm 304 stainless steel door outer

•1.0mm press formed vitreous enamelled door inner

•High density fibreglass insulated

•Stay cool stainless steel door handle with cast metal handle mounts

•Supplied with two chrome wire oven racks

Controls

•Large easy use control knobs - heat resistant reinforced

•Easy view control settings on knobs

Target top

•Variable high to low burner control

•Single control knob for burner and pilot system

•Flame failure pilot burner

•Manual pilot ignition for reliable operation

Oven

•Separate temperature and top heat power regulation controls

•50-320˚C thermostatic control

•Lo-Hi top heat control

•Indicator lights for power and heating

Cleaning and Ser vicing

•Removable oven racking and sole plate

•Easy clean vitreous enamel oven and door inner

•Easy clean stainless steel exterior

•Fully serviceable from front of unit

•Door hinge spring adjustable on unit (door outer removed)

•Door disengages for lift off removal and increased service access

•Access to all parts from front of unit
