Electronic analog exposure display, Lens aperture ring

Electronic analog exposure display

The following examples show electronic analog exposure display indications.

The electronic analog exposure display blinks when subject brightness is beyond the camera’s exposure range.

In 1/3 EV steps	In 1/2 EV steps	In one EV steps
Correct exposure	Correct exposure	Correct exposure

–2/3 EV

–1/2 EV

Under –3 EV

Over +3 EV

+1/2 EV

+1 EV

Lens aperture ring

When a CPU Nikkor lens other than G-type is not set to its minimum aperture setting, ƒEE blinks in the top LCD panel and viewfinder and the shutter locks.

Non-CPU lens

When a non-CPU lens is attached and the maximum aperture is specified in “Non- CPU lens data” (x 144), aperture value is displayed in the top LCD panel, rear LCD panel (in detailed or large display) and viewfinder. In this case, aperture can be set to an intermediate value with the aperture ring but the display only shows changes in one EV steps. When the maximum aperture is not specified, aperture display shows the step difference from the maximum aperture (i.e., ∂2: two steps from maximum aperture); set/confirm aperture with the lens aperture ring.

Exposure factor with AF Micro-Nikkor lens

When an AF Micro-Nikkor lens is attached and you’re setting aperture using Sub- Command Dial aided by an external exposure meter, you do not need to take the exposure factor into consideration. Exposure compensation is required only when setting aperture using the lens aperture ring.

CSM b1: Shutter speed/aperture value displayed in the top LCD panel, rear LCD panel (in detailed or large display) and viewfinder can be set to change in steps of 1/2 or one EV (x 97).

CSM b5: In Manual exposure mode, the slowest shutter speed can be prolonged from 30 sec. to 30 min. (x 98).

CSM f4: When a lens other than G-type is attached, aperture can be set to be adjusted using only the lens aperture ring (x 110). Also, shutter speed can be set to be adjusted using the Sub-Command Dial and aperture with the Main- Command Dial (x 109).

Detailed Operation

F6 specifications

The Nikon F6 is a quintessential piece of camera engineering that pays homage to Nikon's long history of film photography while seamlessly integrating modern technology. Released in 2004, the F6 stands as Nikon's flagship 35mm film camera and serves as a crucial tool for both professional photographers and film enthusiasts alike.

At its core, the Nikon F6 boasts an impressive array of features aimed at enhancing user experience and image quality. One of the standout characteristics is its advanced multi-area 1005-pixel Matrix Metering system. This sophisticated metering technology dramatically improves exposure accuracy by analyzing the scene and making precise adjustments based on lighting conditions. Coupled with a five-frame-per-second continuous shooting speed, the F6 ensures that users can capture fast-moving subjects without missing a moment.

Another highlight of the F6 is its autofocus system. Featuring Nikon's Multi-CAM 2000 autofocus module, the camera offers 11 focus points with excellent precision, even in challenging lighting conditions. The camera’s focus tracking capabilities allow for better subject retention and improved overall performance during dynamic shooting scenarios.

In terms of build quality, the Nikon F6 is constructed with durability in mind. It features a robust magnesium alloy body that is both lightweight and resistant to harsh weather, allowing photographers to shoot in various environments without concern for the camera's longevity. The thoughtful design includes a clear and intuitive interface, with a large, bright viewfinder that provides an accurate field of view and precise framing.

Moreover, the F6 integrates advanced technologies such as the option for custom functions, allowing photographers to tailor the camera to their shooting style. The camera is also compatible with a wide range of Nikon F-mount lenses, providing users with exceptional versatility and creative options.

Perhaps one of the most appealing characteristics of the Nikon F6 is its ability to create stunning image quality with traditional film. Photographers can experience the unique qualities and tonal range that come from shooting on film, making the F6 a perfect bridge between classic photography and contemporary techniques.

In conclusion, the Nikon F6 is a remarkable epitome of film camera technology, blending time-tested features with advanced functionalities that enhance the photographic experience. Whether for professional use or passionate hobbyists, the Nikon F6 continues to captivate and inspire photographers, ensuring that the tradition of film photography remains vibrant and relevant in today’s digital age.
