Training Manual
Connections and Components that plug into the ADT LCB (PN: 721-1176)
A. Brake Style Selector Switch (J2) – This switch allows the LCB to work with either brake style see document number
B. CN7 - 8 Pin Connector – This connector is not used on this generation of the E Series TBT. The previous generation with Upper Body Arm movement (Select Fit) need this connector.
STAR TRAC FITNESS | 13 of 19 | |
|
