TOKINA Co.,Ltd.

MOTORIZED ZOOM LENS

Security Products Division

120-4 NOZUTA-MACHI,MACHIDA-SHI, TOKYO, 195-0063 JAPAN TEL:+81-42-734-8912 FAX:+81-42-735-1463 E-mail:cctv@tokina.co.jp

TM10Z0818GAIPN

f = 8-80mm F1.8 VIDEO IRISW/PRESET

SPECIFICATION

















MODEL NUMBER



TM10Z0818GAIPN



IMAGE FORMAT

1/2inch



FOCAL LENGTH

880mm



MAXIMUM APERTURE



F1.8



APERTURE RATIO

F1.8360



BACK FOCAL LENGTH

11.70mm





M.O.D.



1.5m



ANGLE



DIAGONAL

W54.3°

T5.8°



OF



HORIZONTAL

W43.4°

T4.6°



VIEW



VERTICAL

W33.4°

T3.4°





FILTER SIZE

M46mm P=0.75



DIMENSIONS

W65.0×H75.3×L102.5mm





WEIGHT

500g



OPERATING TEMPERATURE RANGE

10

45



OPERATING HUMIDITY RANGE

30

70





MOUNT





C



㪘㪬㪫㪦㩷㪠㪩㪠㪪









INPUT VOLTAGE



DC8V16V

CURRENT CONSUMPTION



50mA OR LESS

INPUT SIGNAL



VS OR V SIGNAL

IRIS ACCURACY

±15% AT VIDEO SIGNAL LEVEL



SENSITIVITY

0.5 1.0Vpp

AT VIDEO SIGNAL LEVEL

RESPONSE SPEED



APPROX.2 SECONDS

㪝㪦㪚㪬㪪㪆㪱㪦㪦㪤

䇭䇭䇭䇭䇭INPUT VOLTAGE

DC6V12V

䇭䇭CURRENT CONSUMPTION

50mA OR LESS

䇭䇭䇭MOTORIZATION SPEED

APPROX.3 SECONDS

㪚㪘㪙㪣㪜㩷㪚㪦㪥㪥㪜㪚㪫㪠㪦㪥





㪝㪦㪚㪬㪪







CABLE COLOR

POLARITY

DIRECTION



BLACK

+

INF.



GREEN





BLACK

NEAR



GREEN

+





㪱㪦㪦㪤







CABLE COLOR

POLARITY

DIRECTION



RED

+

WIDE



YELLOW





RED

TELE



YELLOW

+





㪘㪬㪫㪦㩷㪠㪩㪠㪪







CABLE COLOR

CONNECTION





RED

POWER(DC8V16V)





WHITE

VS OR V SIGNAL





GREEN

REMOTE





BLACK

GND





㪧㪦㪫㪜㪥㪫㪠㪦㪥㩷㪤㪜㪫㪜㪩㪄㪧㪩㪜㪪㪜㪫

CABLE COLOR

CONNECTION

PURPLE

POT.SUPPLY

GRAY

ZOOM POT.WIRE

ORANGE

POT.RETURN

BLUE

FOCUS POT.WIRE

&'5+)0#0&52'%+(+%#6+105#4'57$,'%661%*#0)'9+6*176016+%'24+06'&+0,#2#0

Page 1
Image 1
Tokina TM10Z0818GAIPN manual Motorized Zoom Lens, Specification
