DATA AND FACTS: TLP-470 AND TLP-471

LCD Panel



3 x 0,9 inch polysilicon TFT (MLA-technique)



Resolution



SVGA 800 x 600, XGA compressed

No. of image dots

1,557,504



Brightness



1,200 ANSI lumens

Colour reproduction

16.7 mio. colours simultaneously

Contrast



400:1



Lamp



150 W UHP lamp



Service life of lampe

up to max. 2,000 operation hours

Horizontal-/vertical frequency

fH 15.63 - 93 kHz, fV 50 - 85 Hz



Video compatibility

NTSC, PAL, SECAM

Lens



F = 1.8 - 2.1 / f = 36 - 47 mm zoom and focus



Keystone correction

automatic and adjustable

Picture size (diagonal)

1.5 m - 7.6 m



Projection distance

1.1 m - 10 m

Inputs



Video: RCA pin, S-Video/ DVD







Audio: stereo mini jack





RGB: D-sub 15 pin

Outputs



RGB: D-sub 15 pin







Audio: stereo mini jack

Serial interface



RS-232C



Power supply



AC 100-240V, 50/60 Hz

Audio



Integrated loudspeaker 1W



Dimensions

TLP-470/471

(WxHxD) 318 x 87 x 233 mm /318 x 87 x 288 mm

Weight

TLP-470/471

3.7 kg /4.5 kg



Accessories



RGB cable, Remote control, Mac adapter, soft case,





Mac/audio/video cabel, instructions,





batteries, lens cap

TLP-470

HIGHLIGHT: INTEGRATED DOCUMENT CAMERA

Camera system

1/3" CCD, 810,000 pixel



(1,024 x 768 XGA-resolution)

Camera lens

Manual zoom and focus,



automatic diaphragm adjustment,



automatic white balance

Projection distances:

10.0 m

7.92-9.57 m

3.94-4.76 m

2.35-2.84 m

1.1 m

7.6m

5.1m

3.8m







2.5m







1.5m







picture size (diagonal)



Toshiba sales partner :

471

Optional:

Hardcase, Combi-bag

(Projector + Notebook)

Choose freedom.
