Model #: BP72V15-2U

BP72V15-2U - External Battery Pack for UPS System

Highlights

Extends runtime of select compatible Tripp Lite UPS Systems with 72VDC

black 3-point external battery connector

Simple installation; 2U rackmount, tower and stack adaptable

2-year warranty

Description

BP72V15-2U rack/tower external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite systems.

Multi-use form factor supports configuration in stacking, upright tower and rackmount applications using only 2 rack spaces (2U). Upright tower

configuration supported with optional 2-9USTAND accessory. Includes heavy gauge cabling with high current DC connector for simple installation.

COMPATIBLE UPS SYSTEMS - SU3000RTXR3U, SU3000RTXL3U, SUINT3000RTXL3U, SU3000RTXL3UHV and other Tripp Lite UPS systems

that specify the use of this battery pack.

Package Includes

BP72V15-2U external battery pack

Mounting hardware

Warranty information

Instruction manual

Features

Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems

Supports stacking or rackmount installation using only 2 rack spaces (2U)

Supports upright tower installation with optional 2-9USTAND accessory (holds 4 battery packs in tower configuration)

Includes heavy gauge cabling with high current DC connectors for simple installation 2 year warranty

Specifications

BATTERY

Expandable battery	No, a max quantity of ONE BP72V15-2U can be connected to the host UPS system. If additional battery packs are to
runtime	be connected, use an expandable model, like BP72V21RT-3U

Connects to UPS via

DC connector

DC system voltage

72VDC

Typical battery lifespan

4-6 years typical (North America)
