Tripp Lite BP72V28RT-3U specifications Highlights, Description, Features, Specifications, Battery

Tripp Lite 1111 West 35th Street Chicago, IL 60609 USA Telephone: +(773) 869 1234 E-mail: saleshelp@tripplite.com

Model #: BP72V28RT-3U

BP72V28RT-3U - External Battery Pack for UPS System

Highlights

Extends the runtime of select compatible Tripp Lite UPS systems with 72VDC

external battery connector

Simple installation; 3U rackmount, tower and stack adaptable

2-year warranty

Description

BP72V28RT-3U rack/tower external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite systems.

Multi-use form factor supports configuration in rackmount or stacking applications using only 3 rack spaces (3U). Upright tower configuration

supported with optional 2-9USTAND accessory. Includes heavy gauge cabling with high current DC connector for simple installation. Additional DC

connector enables the daisy-chaining of multiple external battery packs for longer extended run capability. COMPATIBLE UPS SYSTEMS -

SU3000RTXL3U, SUINT3000RTXL3U, SU3000XL, SU2200XL and other Tripp Lite UPS systems that specify the use of this battery pack.

Applications

Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems. Battery pack may be ordered at time of original UPS purchase or sourced at a later date to extend runtime performance if site power conditions deteriorate and longer battery runtime is desired.

Package Includes

BP72V28RT-3U external battery pack

Mounting hardware

Warranty information

Instruction manual

Features

Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems

Supports stacking or rackmount installation using only 3 rack spaces (3U)

Supports upright tower installation with optional 2-9USTAND accessory (holds 3 battery packs in tower configuration)

Includes heavy gauge cabling with high current DC connectors for simple installation 2 year warranty

Specifications

BATTERY

Expandable battery runtime Yes, DC connector accepts daisy-chaining of multiple external battery packs for extended runtime operation
