				S T E P 4
Elevation A/D appears in the left window. PWM value appears in the dot matrix window, and speed appears in the right window. “CALIBRATION PASSED” will appear in the alphanumeric window when the auto-calibration is complete. The treadmill will come to a complete stop and return to the start-up screen in the alphanumeric window.	To begin auto-calibration, press SELECT. The treadmill will run through minimum and maximum speed and maximum incline. This will take 3-5 minutes. Let the treadmill perform this complete function before exiting the Engineering Mode.	You need to access User Engineering Mode to run the auto-calibration. With the safety key in place , please hold down SPEED DOWN and SELECT for 5 seconds. When in the User mode, “USER ENG MODE” appears in the alphanumeric window. To access the data press the ELEVATION keys until “AUTO - CALIBRATION” appears.	DO NOT STAND ON THE BELT WHEN PERFORMING AUTO-CALIBRATION	AUTO-CALIBRATION

BLUE BAG

INCLUDED
HARDWARE	BAG
	ORANGE

Screwdriver

M8 x 15L Socket Head Quantity: 4 8.2x19x2T Flat Washer Quantity: 4 6x20x2T Flat Washer

M10 x 15L Bolt	Quantity: 4	10.2x19x2T Flat Washer	Quantity: 4
M8 x 15L Socket Head	Quantity: 8	8.2x19x2T Flat Washer	Quantity: 8	PINK BAG

Quantity: 4	6x13x2T Arc Washer	Quantity: 2
	15L Socket Head	Quantity: 6
	M6 x
	x 15L Flat Head	Quantity: 2
	M8
	12L Phillips Head	Quantity: 2
	M5 x

T9800 Series

TREADMILLS

A s s e m b l y G u i d e

PARTS INCLUDED	8mm T-Shaped Wrench
&
TOOLS, HARDWARE,	Wrench	5mm L-Shaped Wrench
	L-Shaped
	6mm

PARTS BOX Water Bottle, Qty: 1 Handlebar Covers, Qty: 2 Safety Magnet Key, Qty: 1 Color-coded Hardware Bags
