VIZIO 60HZ E SERIES User Manual

E420VA

Panel

Resolution

Pixel (Dot) Pitch

Display Compatibility

Colors

Brightness

Contrast with DCR

Response Time

Viewing Angle

Inputs

Outputs

Features

Speakers

Panel Life

Power

Input

Voltage Range

Power Consumption

Specifications

42” Diagonal (42.02” Diagonal viewing), 16:9 Aspect Ratio

1920 x 1080 pixels

0.4845mm x 0.4845mm

1080p (FHDTV)

1.06 Billion

500 cd/m2 (typical)

50000 :1 (typical)

5ms (typical)

Horizontal and Vertical 178° (typical)

1x Coaxial RF (ATSC/QAM/NTSC), 4x HDMI with HDCP 1x Component YPbPr plus Stereo Audio, 1x RGB PC plus Stereo Audio (1/8” stereo jack), 1x S-Video plus Stereo Audio, 1xUSB

1x Optical Audio (SPDIF Optical), 1x Headphone

ATSC/Clear QAM Tuner, Noise Reduction, CC, V-Chip 2.0, 3D Comb Filter, Freeze, Picture Enhancement, Dynamic Contrast Ratio Technology, MPEG-2 Decoding via DTV input, NTSC Video decoding via Video (AV or Component), Progressive Scan Video via HDMI, Component or RGB, HDTV via HDMI, Component or RGB (Set-Top Box required), Computer 640x480, 800x600, 1024 x 768, 1920 x 1080 via RGB or 1920 x 1080 via HDMI, Color Temperature Adjustments of 6500K/9300K/11000K, Independent RED/GREEN/BLUE adjustments for Color Temperature Fine Tuning, Built-in SRS (TruSurroundHD™/TruVolume™) Audio, Supports 1080P (Full HDTV) , 1080i (HDTV) , 720P (HDTV) , 480P (EDTV) and 480i (SDTV) video signals. HDMI V.1.3, Dolby Digital Decoding, SRS TruSurround HD and SRS TruVolume sound enhancement, USB Digital (JPEG photo files) Media Player

2 x 10Watts speakers, '82 +/-3dB@1m/W

60,000 hours to half the original brightness

IEC Connector for direct power line connection

120VAC at 60Hz

88W (Avg), <1W Standby

Environmental Conditions

Operating

Non-Operating

Dimensions

Net Weight

Gross Weight

Certifications

Temperature: 5°C~35°C, Relative Humidity: 20~80%, Altitude: 0~6,561 ft

Temperature: -20°C~50°C, Relative Humidity: 10~90%, Altitude: 0~40,000 ft

39.74” W x 26.71” H x 9.99” D with stand; 39.74” W x 25.28” H x 3.65” D without stand

37.48lbs with stand, 32.19 lbs without stand

47.40lbs

UL, FCC Class B, Energy Star 4.0, ATSC Spec A/65, EIA/CEA-766-A

	56
Version 3/17/2010	www.VIZIO.com
