OPTIONAL PARTS

For Models: RF264LXSQ1, RF264LXST1, RF264LXSB1 (Designer White) (Designer Biscuit) (Black)

Illus. Part

No. No. DESCRIPTION

Parts Not Illustrated and Optional Parts (Not Included)

SPLICING WIRES−−25FT.

LENGTH

242828

Wire, Black



12

Ga. 150 c

242821

Wire, Blue



14

Ga. 150 c

242822

Wire, Brown



14

Ga. 150 c

242830

Wire, Brown



14

Ga. 200 c

242823

Wire, Green



14

Ga. 150 c

242824

Wire, Orange



14

Ga. 150 c

242825

Wire, Red



14

Ga. 150 c

242831

Wire, Red



14

Ga. 200 c

242827

Wire, Yellow



14

Ga. 150 c

REFINISHING MATERIAL

799832 Kit, Porcelain

Repair (White)

242756 Touch−Up

Self−Clean(1/2 Pt)

261582 Grease

Illus. Part

No. No. DESCRIPTION

INSULATION

261514 Insulation,

Fiberglass (1−1/2"

x 24" x 120")

240132 Insulation,

Fiberglass (2−1/2"

x 22" x 120")

PAINT, TOUCH−UP (1/2oz.)

72017 White

4392899 Biscuit

511873 White Porcelain

(2 Oz.)

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

4392901 Biscuit

285006 Superior Black

206922 Primer (White)

PAINT, BULK (1 qt.)

799344 White (Uncut)

4392900 Biscuit (Uncut)

Illus. Part

No. No. DESCRIPTION

ACCESSORY PARTS

241430 Foil, Aluminum

Oven (18" x 25')

3184478 Cleaner, Glass

4396923 Broiler Pan Assy

ANTI−TIP KIT

W10017440 Anti−Tip Kit

WIRING HARNESS PARTS

W10114335

Harness, Wire



(Main)

W10084660

Harness, Wire



Door Switch/Sensor

9761476

Harness, Wire



(Surface Unit)

311227

Wire, Ground

3196154

Screw

313660

Clip, Wire Ground

3196173

Screw

Miscellaneous

3196897 Pin Kit−Dr Removal

W10122973

7

Page 7
