Model D3978 ACCU-SHARPGRINDING JIG | Woodstock instruction

MODEL D3978

ACCU-SHARP®GRINDING JIG

INSTRUCTIONS

To reduce the risk of serious injury when using this grinding jig, take the following precau- tions:

1.GRINDER OWNER'S MANUAL. Read and understand the owner's manual for your grinder and always follow all of the safety precautions and instructions for your grinder.

2.EYE/FACE PROTECTION. Always wear safety glasses or a face shield to protect your- self from flying material.

3.HAND PLACEMENT. Always keep your hands and fingers away from the spinning grinding wheel, and protect yourself from the sharp edges of the tool.

4.SECURE CLAMPING. Make sure the tool is securely clamped in the jig and that the table is firmly locked in the proper position.

Introduction

The Model D3978 Accu-Sharp®Grinding Jig works with the tool rest table of your grinder to properly posi- tion chisels and plane irons up to 2 3⁄4" wide, as shown in Figure 1. The tool clamping jig uses a special plastic rod and pads to slide the tool from side-to-side across the auxiliary table and the grinding wheel.

If you need help with your new grinding jig, call Woodstock Tech Support at: (360) 734-3482.

Figure 1. Using the Accu-Sharp Jig to grind the bevel

of a flat chisel.

Inventory

After removing the contents of the shipping package, lay them out and refer to Figure 2 to inventory the components.

Tool

Clamping

Jig

Auxiliary

Table

Mounting

Screws

Figure 2. Model D3978 inventory.
