Zanussi NFRG430, NFRG435 dimensions Range Composition, Functional and Construction Features

RANGE

COMPOSITION

N 900: a range of over 150 models for the professional caterer designed to guarantee the highest level of performance, reliability, energy saving, safety standards and ergonomic operation. These concepts are reflected in the total modularity of the range that ensures innumerable configurations, either free-standing, bridged or cantilever. N900 demonstrates how advanced technology can satisfy the needs of the professional caterer.

The models detailed on this sheet are 23 litre- high productivity fryers in gas version.

Model 200355

N 900

GAS HIGH PRODUCTIVITY FRYERS - 23 LT ZANUSSIP R O F E S S I O N A L

FUNCTIONAL AND CONSTRUCTION FEATURES

�Burners with optimized combustion, flame failure device and protected pilot light.

�Working temperature from 110ºC to 185ºC.

�Appliances are supplied for use with natural gas, with LPG conversion jets supplied as standard.

�All models have right-angled side edges to allow flush-fitting joins between units, eliminating gaps and possible dirt traps.

�Additonal overheat safety thermostat.

�Worktop in 20/10 stainless steel. Front and side panels in stainless steel with Scotch Brite finish.

�Oil drainage via a tap into a drainage positioned under the well thus simplifying the consumed oil management and guaranteeing the operator safety.

�Integrated oil filtering system for model NFRG435.

�Oil circulation through a specific pump for model NFRG435

�Feet in stainless steel 50 mm adjustables in height.

�Door with handles in stainless steel.

�Main connections can be via the base of the unit.

Productivity

�45 kg/h of frozen French fries.

�30,6 kg/h of defrosted calamari rings.

TECHNICAL DATA
CHARACTERISTICS	MODELS
	NFRG430	NFRG435
	200351	200355
Power supply	Gas	Gas
External dimensions - mm
width	400	400
depth	900	900
height	1200	1200
height adjustment	50	50
N° of wells	1	1
Usable well dimensions - mm
width	340	340
depth	400	400
height	575	575
Thermostatic	•	•
Thermocople safety valve	•	•
Temperature limiter	•
Maximum Well Capacity -lt	21, 23	21, 23
Power - kW
gas	25	25
Power - kW
installed-electric	0.3	0.3
Net weight - kg.	86	86
Supply voltage	230 V, 1N, 50/60	230 V, 1N, 50/60
Oil filtering system		•
INCLUDED ACCESSORIES
2 HALF SIZE BASKETS FOR HD FRYERS	1	1
OIL FILTER FOR FRYERS		1
RIGHT SIDE DOOR FOR OPEN BASE CUPBOARD	1	1
