WM-120P/S— SUGGESTED SPARE PARTS

WM-120PS 1TO 3 UNITS

WM-120PS 5 TO 10 UNITS

Qty.

P/N

Description

Qty.

P/N

Description

6

491010

RUBBER LATCH ASSY.

10

491010

RUBBER LATCH ASSY.

1

EM200293

PADDLE ARM TOW SIDE

2

EM200293

PADDLE ARM TOW SIDE

1

EM200294

PADDLE ARM CENTER TOW SIDE

2

EM200294

PADDLE ARM CENTER TOW SIDE

1

EM200295

PADDLE ARM CENTER ENGINE SIDE

2

EM200295

PADDLE ARM CENTER ENGINE SIDE

1

EM200296

PADDLE ARM ENGINE SIDE

2

EM200296

PADDLE ARM ENGINE SIDE

3

EM200863

RUBBER BLADE KIT (STEEL DRUM)

6

EM200863

RUBBER BLADE KIT (STEEL DRUM)

3

EM204625

RUBBER BLADE KIT (PLASTIC DRUM)

3

EM204625

RUBBER BLADE KIT (PLASTIC DRUM)

2

EM200297

U-BOLT

4

EM200297

U-BOLT

2

EM200268

U-BOLT

4

EM200268

U-BOLT

2

3530

PADDLE SHAFT, SEAL KIT

4

3530

PADDLE SHAFT, SEAL KIT

2

EM902153

BEARING, PADDLE SHAFT

4

EM902153

BEARING, PADDLE SHAFT

3

EM963157

CONNECTOR BOLT

5

EM963157

CONNECTOR BOLT

1

EM934041

CLUTCH, DRIVEN MEMBER

2

EM934041

CLUTCH, DRIVEN MEMBER

NOTE

Part numbers on this Suggested Spare Parts List may supercede/ replace the P/N shown in the text pages of this book.

WHITEMAN WM-120P/S — PARTS & OPERATION MANUAL — REV. #6 (07/20/05) — PAGE 23
