WM-120P/S —WISCONSIN ENGINE ASSY.

WISCONSIN ENGINE ASSY.







NO

PART NO

PART NAME

QTY.

REMARKS

1

EM937029

9.2HP WISCONSIN ENGINE

1



2

EM940734

KILL SWITCH

1



3

EM203298

ENGINE KILL GROUND WIRE

1



4

EM203299

ENGINEKILL WIRE

1



5

0169

HHCS 3/8-16 X 3”

4



6

10136

FLAT WASHER 3/8”

8



7EM100235 ENGINE SHIM .030

EM100236 ENGINE SHIM .018

EM100237 ENGINE SHIM .010

8EM203007 ENGINE PAD .187



EM203016

ENGINE PAD .135





EM203017

ENGINE PAD .060



9

10133

LOCK NUT 3/8-16

4

10

EM912104

1” PIPE NIPPLE X 10” LONG

1

11

5081

1’ 90 DEG. ELBOW

1

12

EM912097

1’ PIPE NIPPLE X 5” LONG

1

13

EM010009

SQ KEY 1/4 X 1/4 X 1”

1

14

EM961045

SHSS 5/16-18 X 1/2” NYLOC

1

15#

EM925013

LEVER PIN

3

16#

EM925018

SHORT LINK PIN

3

17#

EM925016

LONG LINK PIN

3

18#

EM959012

LEVER

6

19#

EM934054

ROLLER

3

20#

5117

COTTER PIN

9

21#

EM934053

CONNECTING LINK

6

22

9503

SLOTTED HHCS 1/4-20 X 1/2”

1

23#

EM934040

ADJUSTING LOCK

1

24#

EM934039

CLUTCH HOUSING

1

25#

EM918009

SPRING

3

26#

EM934041

SPLINED CENTER W/FACING

1

27#

EM934042

PRESSURE PLATE ASM

1

28#

EM934043

RELEASE SLEEVE

1

29#

EM934045

ADJUSTING RING

1

30#

EM963289

BOLT

2

31#

EM969009

LOCK NUT

2

32#

EM934044

RELEASE BEARING ASM

1

33

EM801570

PILOT BUSHING

1

34

EM934022

CLUTCH ASM ............................................................. 1 .......... INCLUDES ITEMSW/#

WHITEMAN WM-120P/S — PARTS & OPERATION MANUAL — REV. #6 (07/20/05) — PAGE 41

Page 41
