USING THE BLOWER

Vacuuming

Before vacuuming, put on the required safety equipment.

WARNING: When working with the blower, wear the required per- sonal safety equipment:

1.Hearing protection.

2.Eye protection.

3.Protective gloves.

4.Face mask in dusty environments.

When operating the blower, the collection bag must be supported by the shoulder strap. The strap should be worn over the shoulder as shown.

545133423 Rev. 4 9/6/07

WARNING: Always check that the collection bag is intact and the zipper is closed before starting the blower. Never use a damaged bag. There is risk of injury due to flying debris. Be careful, particularly if left hand operation is applied. Avoid any direct body contact with the ex- haust outlet area.

WARNING: Never start the blower if the inlet cover is not closed, is damaged or cannot be closed (except if the vacuum tube is fitted).

WARNING: Do not operate the blower while standing on a ladder or a stand.

Start the blower as described in the Starting and Stopping section. Work according to the following instructions:

1.Do not vacuum large solid objects that can damage the fan, such as wood, cans (tins) or lengths of string or ribbon.

2.Do not let the vacuum tube strike the ground.

3.The collection bag can be emptied by first stopping the unit and then opening the zip- per on the side.

English--- 15
