PREPARATION

Remote Control Battery Installation

The remote control operates on 2 “AAA” batteries.

1.Open the battery compartment cover

Push and pull open the battery compartment cover on the backside in the direction of the arrow, and remove the cover.

2. Install the batteries

Install 2 “AAA” batteries (included) making sure the polarities match the indication inside the compartment.

Handling the Remote Control

Use the remote control within a distance of about 5m (16’) from the front of the unit’s remote control sensor and within an angle of about 30 degrees on both sides.

NOTE Aim the Remote Control to the Monitor IR sensor, Monitor will transmit the commands to the A/V Center trough their HDMI connection.

3.Close the battery compartment cover

Make sure the tabs rest in the corresponding holes a n d p u s h d o w n t h e compartment cover until it clicks shut.

Within 30

Within 30

degrees

degrees

About 3m (10’)

About 3m (10’)



About 5m (16’)

CAUTION

Risk of corrosion or battery leakage. Tampering with batteries may result in physical injury and/or property damage including fire.

Never mix used and new batteries in the device.

Replace all the batteries in the device at the same time.

Remove the batteries if the remote control is not going to be used for an extended period of time.

To avoid possible malfunction, read the following instructions and handle the remote control correctly.

Do not drop or allow impact to affect the remote control.

Do not spill water or any liquid on the remote control.

Do not place the remote control on a wet surface.

Do not place the remote control under direct sunlight or near sources of excessive heat.

Main Unit Installation

Please leave adequate space around the unit in order to avoid increasing the internal temperature. Make sure not to block any ventilation holes.

Do not install the unit in a small space such as inside a cabinet, closet or box without adequate ventilation.

Leave at least 10cm (4") of clearance from each side of the unit and from the top of the unit to ceiling.

10 cm.

10 cm.

10 cm.



10 cm.

10 cm.

10 cm.
