Page 23

SERVICE AND ADJUSTMENTS

ENGINE

TO ADJUST THROTTLE CONTROL CABLE (See Fig. 29)

The throttle control has been preset at the factory and adjustment should not be necessary. Check adjustment as described below before loosening cable. If adjustment is necessary, proceed as follows:

•With engine not running, move throttle control lever to fast position.

•Check that swivel is against stop. If it is not, loosen cable clamp screw and pull cable back until swivel is against stop. Tighten cable clamp screw securely.

TO ADJUST CHOKE CONTROL (See Fig. 30)

The choke control has been preset at the factory and adjustment should not be necessary. Check adjustment as described below before loosening cable. If adjustment is necessary, proceed as follows:

•With engine not running, move choke control (located on dash panel) to full choke position.

•Loosen knob and remove cover assembly from air cleaner.

•Choke should be closed. If it is not, loosen casing clamp screw and move choke cable until choke is completely closed. Tighten casing clamp screw securely.

•Replace air cleaner cover assembly and tighten knob.

TO ADJUST CARBURETOR

Your carburetor is not adjustable. If your engine does not operate properly due to suspected carburetor problems, take your tractor to an authorized service center for repair and/or adjustment.

High speed stop is factory adjusted. Do not adjust - damage may result.

IMPORTANT: NEVER TAMPER WITH THE ENGINE GOVERNOR, WHICH IS FACTORY SET FOR PROPER ENGINE SPEED. OVERSPEEDING THE ENGINE ABOVE T H E F A C T O R Y H I G H S P E E D S E T T I N G C A N B E DANGEROUS. IF YOU THINK THE ENGINE-GOVERNED HIGH SPEED NEEDS ADJUSTING, CONTACT YOUR N E A R E S T A U T H O R I Z E D S E R V I C E C E N T E R / DEPARTMENT, WHICH HAS PROPER EQUIPMENT AND E X P E R I E N C E T O M A K E A N Y N E C E S S A R Y ADJUSTMENTS.

STOP

SWIVELCLAMP SCREW

FIG. 29

CLAMP SCREW

FIG. 30

23
