Poulan 175682 owner manual Suggested Guide for Sighting Slopes for Safe Operation, Sighting Guide

Page 47

SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION

SIGHTING GUIDE

CUT











THIS

OUT

ON

DOTTED



IS A







15°



LINES





SLOPE









ONLY RIDE UP AND DOWN HILL, NOT ACROSS HILL

47

SIGHT AND HOLD THIS LEVEL WITH

SKY LINE OR TREE.

15° MAX.

Operate your Tractor up and down the face of slopes (not greater than 15°), never across the face. Make turns gradu- ally to prevent tipping or loss of control. Exercise extreme caution when changing direction on slopes.
