McCulloch ESV1750-14, ESV1816, ESV1414, ESV1914, ESR1816 Declaration of Conformity, Technical Data

N. DECLARATION OF CONFORMITY

The undersigned, authorized by H.O.P.I., declares that the following products model: type ES15, ES 15/1, ES 15/2, ES16, ES 16/1, ES18 starting from 2004 onwards, manufactured by H.O.P.I., Valmadrera, Italy, comply with European Directive: 98/37/EEC (Machine Directive), 93/68/EEC (EEC Marking Directive) & 89/336/CEE (Electromagnetic Compatibility Devices), directive 2000/14/EEC (Enclosure V).

The following harmonised standards have been applied: EN 50144-1, EN 50144-2-13, EN 55014-1, EN 55014-2. The supplied chain saw conforms with the example that underwent EU type approval. The certificates are numbered: 04/0097, 04/0060.

Registered body: 0717, Nemko S.p.A. - Via Trento e Trieste, 116 - I-20046 Biassono (Mi), has carried out EU type approval in accordance with article 8 section 2c.

Valmadrera, 10/01/2006

Giuseppe Todero (Technical Manager)

Husqvarna Outdoor Products Italia S.p.A.

Via Como 72, 23868 Valmadrera (Lecco)

ITALIA

O. Technical Data

Type:	ES 15		ES 16	ES 18
	ES 15/1	ES 16/1
	ES 15/2
Dry weight (Kg)	3,5		3,5	3,5
Oil tank volume (cm3)	200		200	150
Bar length (cm/inches)		30/12” 35/14’’	40/16”
Chain		MPG370GLX	91VJ
Chain pitch (inches)	3/8		3/8	3/8
Vibration
Front handle (m/s2) (ISO 7505)	3,5		3,5	1,96
Rear handle (m/s2) (ISO 7505)	7,9		7,9	7,30
Measured sound power level LWav dB(A) (ISO 9207)	111,14		111,14	103
Guarateed sound power level Lwav dB(A) (ISO 9207)	113		113	104
Sound pressure level at operator’s ear dB(A)	98		98	94
(EN 27182)
Minimum wire cross-section (wires num./mm2)	2x1		2x1	2x1
Maximum cable length (m)	30		30	30

ENGLISH - 12
