Deck Lift Handle Assembly (Except 48" Model)

Item	Part No	Qty	Description	Note
1	7041924		HANDLE, Deck Lift
2	7041925		BRACKET, Pivot Support
3	7058090		LEVER, Deck Lift/Handle Release
4	7029040		WASHER, Slipper
5	7046489		SPRING, Torsion (Deck Position)
6	7090072	2	SCREW, 1/4-20 x 5/8" Hex head Cap, Grade 5
7	7091584	3	NUT, 1/4-20 Hex Flange Lock	Was 90583
8	7035489		BAR, Deck Lift
9	7090122	3	WASHER, 3/8" Flat
10	7091503	2	HAIRPIN, 3/32 x 1-1/2"
11	7046392		PIN, 3/8 x 7/8" Large Head Clevis
	7013996		PIN, 3/8 x2"” Clevis
12	7058077		PLATE, Detent
13	7091318		SCREW, 5/16-18 x 3/4" Hex Cap, Grade 5
14	7091601		NUT, 5/16-18 Hex Flange Lock, Grade 5	Was 91070
15	7046457		DECAL, Deck Position
16	7091887		PIN, 3/8 x 1/2" Expanded Head Clevis
17	7046491		PIN, 3/8 x 1-5/8" Clevis
18	7046490		SPACER
19	7091597		PIN, 3/32" x 3/4" Cotter

Footnotes:

YARD CRUISER		Manual No. 7006148
HZ SERIES 3 & YZ SERIES 4	37	TP 400-5010-5-HZ-N
