Snapper HZS15423KVE, HZS18483BVE For gage wheel, Replaces 91514, See decal, Includes items 69

Page 45

42" Mower Deck Assembly (Part 3)

Item	Part No	Qty	Description	Note
43	7035835	4	POST, Anti-Scalp
44	7091328	8	SCREW, 3/8-16 x 1-1/4 Hex Head Cap, GR5
45	7091619	8	NUT, 3/8-16 Hex Flange Lock	Was 90613
46	7029265	4	BOLT, 3/8-16 x 2-5/8” Shoulder	for gage wheel
47	7091585	6	NUT, 3/8-16 Hex Center Lock, GR5 or B
48	7029264	4	WHEEL, Gage
49	7022717	1	ROD, Deck Support
50	7017847	1	RING, .438 External Retaining
51	7075235	1	BELT, HA Section, (94.5” nom. effective length)
52	7028728	2	ADJUSTER, Chain (5/16-18 thread)
53	7028200	2	SWIVEL, Adjustment
54	7090122	5	WASHER, 3/8” SAE Flat	replaces 91514, 91296
55	7091503	3	HAIR PIN, 3/32 x 1-1/2”
56	7024910	1	DECAL, 42 Inch	see decal page
57	7035969	1	SPRING, Extension 1.03 Dia. X 6.8” long
58	7036561	1	BELT GUIDE, 38/42 Idler
59	7012063	2	WASHER, Cone
60	7075707	1	IDLER, Flat (4.00 O.D.)
61	7091553	2	SCREW, 3/8-16 x 1-3/4” Hex Head Cap, GR5
62	7018574	1	IDLER, 4.12” Outside Diameter, Flat
63	7090799	2	BOLT, 5/16-18 x 5/8” Short Neck Carriage, GR5
64	7011791	2	RETAINER, 5/16” Bolt
65	7091315	2	WASHER, .32 x .58 x .08 Split Lock
66	7091537	2	WING LOCKNUT, 5/16-18
67	7091303	2	BOLT, 5/16-18 x 1” Short Neck Carriage, GR5
68	7051401	1	ASSEMBLY, Chute & Decal	includes items 69 & 70
69	7051401	1	WELDMENT, Side Chute	Was 40497
70	7013010	1	DECAL, Danger, Cut Finger (CPSC)
71	7091601	2	NUT, 5/16-18 Hex Flange Lock, GR5
72	7023606	2	CAP, Vinyl
73	7046720	1	DECAL, Chute/Deflector

Footnotes:

YARD CRUISER		Manual No. 7006148
HZ SERIES 3 & YZ SERIES 4	45	TP 400-5010-5-HZ-N
