Snapper YZ20484BVE, HZS18483BVE, HZS15423KVE, YZ16424BVE manual Includes Items 2 thru, Was

Page 7

Caster, Front Wheel & Tire Assembly

Item	Part No	Qty	Description	Note
1	7053980	2	ASSEMBLY, Front Wheel & Tire (Complete)	(Includes Items 2 thru 6)
2	7035618		TIRE, 11 x 4.00-5, Smooth Tread
3	7072197		RIM, Caster Wheel	Was 29122
4	7014247		FITTING, Lube
5	7012234		VALVE, Air (Snap-in)
6	7012709	2	RING, 1" External Retaining
7	7023556	2	BUSHING, Caster
8	7013864	2	LUBE FITTING, Straight (press-fit for .187 dia. Hole)
10	7041783	2	CASTER, Pivot Yoke
11	7090839	2	NUT, 7/16-14 Hex Center Lock
12	7035359	2	TUBE, 5/8 O.D. x 14 Ga. x 4.51
13	7035358	4	BEARING, Ball 5/8 x 1-3/8"
14	7091772	2	SCREW, 7/16-14 x 6" Hex Head Cap, Grade 5

Footnotes:

YARD CRUISER		Manual No. 7006148
HZ SERIES 3 & YZ SERIES 4	7	TP 400-5010-5-HZ-N
