Briggs & Stratton 020252 owner manual Table of Contents, Equipment Description, Safety Rules

Page 2

Section

1

Safety Rules

SAVE THESE INSTRUCTIONS

TABLE OF CONTENTS

Section 1 - Safety Rules . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Section 2 - Features and Controls . . . . . . . . . . . . . . . . . . . 5

Section 3 - Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8

Section 4 - Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 9-12

Section 5 - Product Specifications. . . . . . . . . . . . . . . . . . . 13

Section 5 - Maintenance. . . . . . . . . . . . . . . . . . . . . . . . 13-14

Section 6 - Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Section 7 - Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . 16

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

EQUIPMENT

DESCRIPTION

Read this manual carefully and become familiar with your pressure washer. Know its applications, its limitations and any hazards involved.

This manual contains information for a high pressure washer that operates at 3,400 PSI at a flow rate of

4.0gallons per minute.This powerful, high quality system features large 10” NeverFlat™ wheels, a pump equipped with an automatic cool down system, chemical injection system, nozzle extension with quick connect nozzles, safety goggles, heavy duty 50’ high pressure hose, and more.

Every effort has been made to ensure that information in this manual is accurate and current. However, we reserve the right to change, alter or otherwise improve the product and this document at any time without prior notice.

Copyright © 2005 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power Products Group, LLC.

SAFETY RULES

This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

The safety alert symbol () is used with a signal word (DANGER, CAUTION,WARNING), a pictorial and/or a safety message to alert you to hazards. DANGER indicates a hazard which, if not avoided, will result in death or serious injury. WARNING indicates a hazard which, if not avoided, could result in death or serious injury. CAUTION indicates a hazard which, if not avoided, might result in minor or moderate injury. CAUTION, when used without the alert symbol, indicates a situation that could result in equipment damage. Follow safety messages to avoid or reduce the risk of injury or death.

WARNING

The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.

Hazard Symbols and Meanings

Toxic Fumes

Electrical Shock

Slippery Surface

Fall

Fluid Injection

Fire

Explosion

Hot Surface

Moving Parts

Flying Objects

Kickback
