Chicago Electric 98452 Parts List, Please Read the Following Carefully, Part Description Qty

Page 20

PARTS LIST

Part

Description

Qty







1

Bolt (M6 x 12) w/Lock Washer

9

2

Engine Power Switch

1

3B

Control Panel

1

4

Voltmeter

1

5

Circuit Breaker

1

6

Outlet

2

7

DC Terminal

2

8

Ground Connector

1

9

DC Fuse

1

10

Pilot Light

1

11

Shock Absorber

4

12

Shock Absorber Foot

4

13

Lock Washer Nut (M8)

4

14

Stator Cover

1

15

Alternator Back Cover

1

16

Automatic Voltage Regulator

1

17

Bolt (M5 x 16)

4

18

Rectifier

1

19

Bolt (M5 x 16)

3

20

Cable Sheath

1

21

Bolt (M8 x 224)

1

22

Bolt (M6 x 152)

4

Part

Description

Qty







23

Bolt (M5 x 20)

4

24

Connection Board

1

25

Nut (M5)

4

26

Stator

1

27

Rotor

1

28

Cooling Fan

1

29

Heat Insulation Board

1

30B

Fuel Tank

1

31

Fuel Filter

1

32

Seal Ring

1

33

Fuel Tank Cap

1

34

Fuel Gauge

1

35B

Bolt (M5 x 10)

2

36

Lock Washer Bolt (M6 x 12)

4

37

Spacer

4

38

Rub Washer

4

39

Bush

4

40B

Fuel Valve

1

41B

Frame

1

42

Switch Box Cover

1

43

Engine

1

44

Carbon Brush

1

NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts.

PLEASE READ THE FOLLOWING CAREFULLY

The manufacturer and/or distributor has provided the parts list and assembly diagram in this manual as a reference tool only. Neither the manufacturer or distributor makes any representation or warranty of any kind to the buyer that he or she is qualified to make any repairs to the product, or that he or she is qualified to replace any parts of the product. In fact, the manufacturer and/or distributor expressly states that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer. The buyer assumes all risk and liability arising out of his or her repairs to the original product or replacement parts thereto, or arising out of his or her installation of replacement parts thereto.

SKU 98452

For technical questions, please call 1-800-444-3353.

Page 20
