Appendix B. Rack Mounting Options for 1U and 2U Intel® Communications Rack Mount Servers

Rack mounting kits for 2-post or 4-post, 19-inch or 23-inch racks are offered for this product. Please refer to the tables below for the correct options to suit your needs.

All rack mount kits listed are suitable for 1U and 2U Intel® Communications Rack Mount Servers. Installation instructions are included in each kit.

2-post Rack Mounting Kit Options

Rack width

Post depth

Rack fastener hole spacing

Applicable kits:

19 inch 23 inch 3 inch 5 inch EIA-Wide EIA-Universal ETSI

TMLCMOUNT21

TMLPMOUNT41

TMLPMOUNT51

TMLPMOUNT52

4-post Rack Mounting Kit Options



Rack width

Front-post to

Rack fastener





rear-post distance



hole spacing



Applicable kits:



























19 inch

23 inch

Min

Max

EIA-



EIA-



ETSI









(inches)

(inches)

Wide



Universal



































TMLPMOUNT41





20

24































TMLPMOUNT51





20

24































TMLPMOUNT52





20

24































TMLPSLIDE01





22.5

28 or 34††











The TMLPSLIDE01 kit contains server securing brackets. The rails and other options for mounting the server are available through other venders such as Accuride (http://www.accuride.com/index2.php).

††34-inchspan requires the optional Accuride "Long Bracket" kit.

5/18/2007

v1.2

14 of 21
