Intel IXD1110 manual Power Test Points Sheet 2, Ground Test Points

Page 23

IXD1110 Demo Board

Table 9. Power Test Points (Sheet 2 of 2)

Test Point

Symbol

Description







TP20

Vdd_3P3

3.3 V rest of the board







TP22

TxAVTT_A

SerDes Tx Block A 1.8 V







TP23

TxAVTT_B

SerDes Tx Block B 1.8 V







TP24

RxAVTT_C

SerDes Rx Block C 1.8 V







TP25

RxA25_A

SerDes Rx Block A 2.5 V







TP26

RxAVTT_A

SerDes Rx Block A 1.8 V







TP27

TxA25_B

SerDes Tx Block B 2.5 V







TP28

RxA25_B

SerDes Rx Block B 2.5 V







TP29

RxAVTT_B

SerDes Rx Block B 1.8 V







TP30

TxAVTT_C

SerDes Tx Block C 1.8 V







TP31

RxA25_C

SerDes Rx Block C 2.5 V







NOTE: TP = Test Point

Table 10 lists the various ground test points provided on the IXD1110 demo board.

Table 10. Ground Test Points

Test Point

Symbol

Description







TP10











TP11











TP12











TP13

GND

Ground Test Points



TP14











TP15











TP16











TP17











NOTE: TP = Test Point









Development Kit Manual

23

Document Number: 250807

Revision Number: 003

Revision Date: June 27, 2003
