Chapter 1 Introduction

Features Summary

CPU

Socket 478 for Intel® Pentium ® 4 (Northwood) with HT Technology

Intel® Pentium ® 4 533/400MHz FSB

2nd cache depends on CPU

ChipsetNorth Bridge: VIA P4M266A/P4M533

South Bridge: VIA VT8235/VT8237R

Memory

2 184- pin DDR DIMM sockets, supports up to 2GB DRAM (Max)



Supports DDR266/DDR200 DIMM



Supports only 2 .5V DDR SDRAM







Slots

1 AGP slot 4X (1.5V) device support



3 PCI slots support 33M Hz & PCI 2.2 compliant





On- Board IDE

2 IDE controller provide IDE HDD/CD-ROM(IDE1, IDE2) with PIO, Bus





Master (Ultra DMA33/ATA66/ATA100/ATA133) operation modes



Can connect up to 4 IDE devices







On -Board Floppy

1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M and 2.88M bytes

On-Board Peripherals

1 Parallel port supports Norm al/EPP/ECP mode



1 Serial port (COMA), 1 VGA port, COMB onboard



6 USB 2.0/1 .1 ports (4 x Rear, 2 x Front by cable)



1 Front Audio connector



1 PS/2 Keyboard



1 PS/2 Mouse





On -Board LAN *

Builit-in VIA 6103 chipset *



1 RJ45 port *





On-Board Sound

VIA VT1616 CODEC



Support 2/6 channel



Line Out / Line In / Mic In



CD In





BIOS

Licensed AWARD BIOS



Supports Q- Flash

I/O Control

ITE8705

Hardware M onitor

CPU Fan Revolution detect



CPU Fan Fail Warning



CPU tem perature detect



System Voltage Detect







Additional Features

Supports @BIOS



Supports EasyTune 4

Form Factor

Micro ATX size form factor, 24.5cm x 20 .8cm

"*" For 8VM533M-RZ only.
