NEC LCD1510+ user manual Fiche technique

Page 35

Fiche technique

Caractér. techn.

Moniteur

Remarques

du moniteur

MultiSync® LCD1510+MC

Module LCD

Diagonale :

15 pouces

Matrice active; transistor à film fin (TFT);



Surface utile :

15 pouces

affichage àcristaux liquides (LCD); pas 0,30 mm;

Résolution (nombre de pixels) :

Paysage : 1 024 x 768

technologie XtraView®; uminance blanche 180 cd/





Portrait : 768 x 1 024

m2; taux de contraste caractéristique 200:1.

Signal d'entrée

Vidéo :

ANALOGIQUE O,7 Vp-p/75 Ohms





Sync :

Synchro séparée niveau TTL.







Positif/négatif sync. horizontale







Positif/négatif sync. verticale







Sync. composite (positif/négatif) (niveau TTL)







Synchro sur le vert (positive) 0,7







Vp-p et synchro négative 0,3 Vp-p



Couleurs d'affichage

Entrée analogique :

16 777 216 couleurs

Dépend de la carte vidéo utilisée

Viewing Angle

Left/Right :

80°





Up/Down :

80°



Gamme de

Horizontale :

24,8 kHz à 60 kHz

Automatique

synchronisation

Verticale :

56,2 Hz à 75 Hz

Automatique

Résolutions acceptées

Paysage :

720 x 400* : texte VGA







640 x 480* @ 60 Hz à 85 Hz







800 x 600* @ 56 Hz à 85 Hz







832 x 624* @ 75 Hz







1 024 x 768 @ 60 Hz à 75 Hz ...................... NEC recommande une résolution à 75 Hz



Portrait :

480 x 640* @ 60Hz à 85Hz

pour des performances d'affichage optimales.









600 x 800* @ 56 Hz à 85 Hz







624 x 832* @ 75 Hz







768 x 1 024 @ 60 Hz à 75 Hz ...................... NEC recommande une résolution à 75 Hz







pour des performances d'affichage optimales.

Zone d'affichage active

Paysage : Horiz. :

304 mm/12,0 pouces





Vert. :

228 mm/9,0 pouces





Portrait : Horiz. :

228 mm/9,0 pouces





Vert. :

304 mm/12,0 pouces



Alimentation



CA 100–120 V/220–240 V, 50-60 Hz



Tension d'alimentation



0,7 A @ 100–120 V/0,4 A @ 220–240 V



Dimensions

Paysage :

381 mm (L) x 392 mm (H) x 217 mm (P)







15,0 pouces (L) x 15,4 pouces (H) x 8,5 pouces (P)



Portrait :

312 mm (L) x 427 mm (H) x 217 mm (P)







12,3 pouces (L) x 16,8 pouces (H) x 8,6 pouces (P)

Réglage de la hauteur :

55 mm/2,2 pouces



Poids



7,0 kg/15,4 livres



Considérations environnementales





Température de fonctionnement :

5 °C à +35 °C/41 °F à 95 °F





Humidité :

30 % à 80 %





Altitude :

0 à 10 000 pieds



Température de stockage :

-10 °C à +60 °C/14 °F à 140 °F





Humidité :

10 % à 85 %





Altitude :

0 à 45 000 pieds











*Résolutions interpolées : Quand les résolutions affichées sont inférieures au nombre de pixels du module LCD, le texte peut apparaître craquelé et les lignes plus épaisses. Ceci est normal et nécessaire pour toutes les technologies d’affichage sur panneaux plats pour lesquels chaque point de l’écran occupe réellement un pixel. Pour agrandir la résolution à celle du plein écran, une interpolation mathématique de celle-ci est nécessaire. Quand cette résolution interpolée ne correspond pas exactement à un multiple entier de la résolution d’origine, la nécessaire interpolation mathématique peut faire que certaines lignes apparaissent plus épaisses que d’autres.

NOTA : Les spécifications techniques sont susceptibles d’être modifiées sans préavis.
