Philips 220VW9FB 97 user manual Model

Page 34

Philips Pixel Defect Policy

One lit red, green or blue sub pixel

Two adjacent lit sub pixels:

-Red + Blue = Purple

-Red + Green = Yellow

-Green + Blue = Cyan (Light Blue)

Three adjacent lit sub pixels (one white pixel)

A red or blue bright dot must be more than 50 percent brighter than neighboring dots while a green bright dot is 30 percent brighter than neighboring dots.

Black Dot Defects Black dot defects appear as pixels or sub pixels that are always dark or 'off'. That is, a dark dot is a sub-pixel that stands out on the screen when the monitor displays a light pattern. There are two types of black dot defects:

One dark sub pixel

Two or three adjacent dark sub pixels

Proximity of Pixel Defects

Because pixel and sub pixels defects of the same type that are near to one another may be more noticeable, Philips also specifies tolerances for the proximity of pixel defects.

Pixel Defect Tolerances

In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.

BRIGHT DOT DEFECTS



ACCEPTABLE LEVEL

MODEL



220VW9

file:///D/Philips (G)/Philips (G)/lcd/manual/ENGLISH/220VW9/product/pixel.htm(第 2/3 页)3/3/2008 6:41:17 PM
