Baracoda All in One Printer manual Attempt Negociated Sniff

Page 34

Data Capture

for Workforce

in Motion

MinSniff = 0x0050

MaxSniff = 0x00F0

Attempt = 0x0008

Timeout = 0x0030

MaxSniff and MinSniff are only used for sniff negociation between the Smartodule and the other BT device. If both sides allow sniff value MaxSniff, then MaxSniff will be used. If the other side does not accept Sniff values MinSniff to MaxSniff, no sniff will be used.

Values are in number of Bluetooth slots (1 slot = 625µs) Set MinSniff and MaxSniff to 0 to disable Sniff. MinSniff must be inferior to MaxSniff.

Possible values for MinSniff and MaxSniff are 0x12 to 0xFFFF. Sniff attempts of 0 is not allowed.

Warning: Setting MaxSniff to 0xFF means a sniff period of 40s! You will have very very low data rate.

Note: This setting takes effect immediately.

Attempt

Negociated Sniff









For further details on Sniff values, see the Bluetooth spec 1.1, chapter 10.8.2

















Command

Header

Length

Payload



Answer















Set link timeout

0x19

00 02

[MSB of link Tmo, LSB of link Tmo]



0x19

00 01 01 if done











0x19

00 01 00 if not















The link Time Out is a multiple of 625µsec (625µs = 1 Bluetooth slot) (default 0x7D00 (=20s))

This Timeout is used by the Link Manager to monitor the Bluetooth Link. If there is no answer from the other device after this timeout, the Link Manager assumes that we are disconnected. By default, this value is set to 20 seconds. You can go down to 1s, but then you can have disconnection even if it’s only a temporary perturbation.

This value will take effect at the next connection.

Command

Header

Length

Payload

Answer











Get link timeout

0x18

00 00

-

0x18 00 02 [MSB of link Tmo, LSB of link Tmo]











ToughRunners / ScanWear – Communication Protocol v1.2

- 34 -

Image 34
