Dukane 28A8049B Connection to the Mouse Control, ADB Mouse, Serial Mouse, USB Mouse, PS/2 Mouse

CONNECTION TO THE MOUSE CONTROL

ADB Mouse	Projector
		1
		2
CONTROL Terminal	DATA 3
		4
		5
D-sub 15-pin shrink jack		6
	RTS 7
6117128139141015		8
	GND 10
	+5V	9
		11

12

13

14

15

Computer

1ADB

2(POWER ON)

3+5V

4 GND	Mouse jack
	Mini DIN 4-pin
	4	3
	2	1

Serial Mouse					Projector		Computer
						1	1	CD
						2	2	RD
CONTROL Terminal						3	3	TD
						4	4	DTR
D-sub 15-pin shrink jack						5	5	GND
					SEL0 6		6	DSR
6	7	8	9	10	RTS 7		7	RTS
	11	12	13	1415	GND	10	8	CTS
						8
						11

12

13 TD 14 15

Mouse jack D-sub 9-pin

1 2 3 4 5

6 7 8 9

USB Mouse

USB jack		Projector
(B type)
2	1	+5V	1
		—DATA 2
		+DATA	3
3	4	GND	4

	USB cable
PS/2 Mouse	Projector
		1
	CLK 2
CONTROL Terminal	DATA 3
		4
		5
D-sub 15-pin shrink jack	SEL0 6
	RTS 7
6117128139141015	GND	8
		10
	+5V	9
		11

12

13

14

15

Computer

1+5V

2—DATA

3+DATA

4GND

Computer

1DATA

3GND

4+5V

5CLK

USB jack

(A type)

1 2 3 4

Mouse jack

Mini DIN 6-pin

6 5

43

2 1

4
