PC-CARD-DIO48 User's Guide Installing the PC-CARD-DIO48

Details on the CPCC-50F-39 cable are available on our web site at

www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=105&pf_id=1379.

CPCC-50M-4

If your application requires a cable that is longer than one meter in length, use the CPCC-50M-4 four-inch cable, and connect to a C50FF-xcable.

50	49
		50
		1
2	1	Dot
		50-pin micro connector.
50-pin male IDC connector.		Connect to the I/O connector
		on the PC-CARD
Connect to a C50FF-x cable.		with the dot facing UP.

Figure 9. CPCC-50M-4 cable connections

Details on the CPCC-50M-4 cable are available on our web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=96&pf_id=1380.

C50FF-x

2	1	The red stripe
		identifies pin # 1

50 49

2 1

50 49

50-pin female	50-pin female
IDC connector	IDC connector

Figure 10. C50FF-x cable

Details on the C50FF-x cable are available on our web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=104&pf_id=136.
