3M MP7730 manual Keystone

Page 19

Operation

Display Menu

Keystone (0-255)

128

160

128

96

Brightness (0-255)

65

128

193

Contrast(0-255)

65

128

193

Color Balance

(0-2)

0	1	2
	1

© 3M IPC 2000

3M™ Multimedia Projector MP7730

19
