ENGLISH

28SPECIFICATIONS

SPECIFICATIONS

22EN33S

Display

Screen Type

TFT (Thin Film Transistor) LCD (Liquid Crystal Display)













Panel,Anti-Glare coating













54.6 cm visible diagonal (21.5 inch)



Pixel Pitch

0.248 mm x 0.248 mm (Pixel Pitch)

Sync Input

Horizontal Frequency

30 kHz to 83 kHz (Automatic)



Vertical Frequency

56Hz to 75Hz (D-SUB)



Input Form

Separate Sync.

Video Input

Signal Input

15 pin D-SUB Connector



Input Form

RGB Analog (0.7 Vp-p/ 75 ohm)

Resolution

Max

D-SUB(Analog) : 1920 x 1080 @ 60 Hz



Recommend

VESA 1920 x 1080 @ 60 Hz

Plug & Play

DDC 2B(Analog)



Power

On Mode : 23 W(Typ.)



Consumption

Sleep Mode ≤ 0.3 W





Off Mode ≤ 0.3 W



Power Input

19 V



1.2 A







AC-DC Adapter

Type ADS-40SG-19-3 19025G, manufactured by SHENZHEN HONOR ELECTRONIC



or Type ADS-40FSG-19 19025GPG-1, manufactured by SHENZHEN HONOR ELECTRONIC



or Type ADS-40FSG-19 19025GPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC



or Type ADS-40FSG-19 19025GPI-1,manufactured by SHENZHEN HONOR ELECTRONIC



or Type ADS-40FSG-19 19025GPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC



or Type ADS-40FSG-19 19025GPB-2,manufactured by SHENZHEN HONOR ELECTRONIC



or Type LCAP21, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE



or Type LCAP26-A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE



or Type LCAP26-E, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE



or Type LCAP26-I, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE



or Type LCAP26-B, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE



or Type PSAB-L203A,manufactured by LG Innotek Co.,Ltd



or Type PSAB-L202B,manufactured by LG Innotek Co.,Ltd



or Type PSAB-L202C,manufactured by LG Innotek Co.,Ltd



or Type PSAB-L202D,manufactured by LG Innotek Co.,Ltd



OUTPUT: 19 V



1.3 A









Dimensions

With Stand

50.9 cm x 38.7 cm x 18.1 cm

(Width x Height x













Without Stand

50.9 cm x 31.3 cm x 5.5 cm

Depth)













Weight

2.6 kg



Tilt Range

-5° to 20°



Environmental

Operating Temperature

10°C to 35 °C

conditions

Operating Humidity

10 % to 80 %

















Storage Temperature

-20°C to 60 °C



Storage Humidity

5 % to 90 % non-Condensing















Stand Base

Attached ( ), Detached (O)

Power cord

Wall-outlet type



Product specifications shown above may be changed without prior notice due to upgrade of product functions.

Page 28 Page 30
Image 29
