ASSEMBLING AND PREPARING 5

Setting up the Monitor set

Attaching the Stand Base

1Place the Monitor set with the screen side down on a flat and cushioned surface.

CAUTION

Lay a foam mat or soft protective cloth on the surface to protect the screen from damage.

21 Attach the Stand Body to the monitor set.

2 Attach the Stand Base.

3 Tighten the screw to the right with a coin.

Detaching the Stand Base

1Place the Monitor set with the screen side down on a flat and cushioned surface.

21 Pull out the Stand Body and Stand Base from the monitor set.

2Turn the screw to the left with a coin.

3Pull out the Stand Base.

Stand Body

ENGLISH

Stand Body

Stand Base

Stand Body

Stand Base

Stand Base
