Sharp XV-Z9000E Selecting the Economy Mode, RS-232C Off Function, Description of RS-232C Off

Page 43

Selecting the Economy Mode

2,3,4

1,5

(GUI) On-screen Display

These functions allow you to reduce the power consumption when the projector is in stand-by mode.

RS-232C Off Function

This projector consumes power when using a computer connected to the RS-232C port. When not using this port, “RS-232C Port” can be set to “” for reducing stand-by power consumption.

Description of RS-232C Off

Stand-by power for RS-232C connection turned off.

RS-232C on

1Press MENU.

2Press / to select “Options”.

3Press / to select “RS-232C Port”.

4Press / to select “” or “”.

5To exit the GUI, press MENU.

•Set “RS-232C Port” to “” when using the SharpVision Manager (supplied).

OperationBasic

On-screen Display

(GUI) On-screen Display

Automatic Power Shut-off Function

When no input signal is detected for more than 15 minutes, the projector will automatically shut off. The on-screen message on the left will appear five minutes before the power is automatically turned off.

Description of Automatic Power Shut-off

Power automatically shuts off after 15 minutes without an input signal.

Automatic Power Shut-off disabled.

1Press MENU.

2Press / to select “Options”.

3Press / to select “Auto Power Off”.

4Press / to select “” or “”.

5To exit the GUI, press MENU.

•“RS-232C Port” is factory preset to “”, and “Auto Power Off” is factory preset to “”.

41
