Allied Telesis AT-GS900/8PS manual Power Supply

Page 30

Chapter 1: Overview

Power Supply

The switch has an internal power supply with a single AC power supply socket on the back panel and autoswitch AC inputs. To power the switch on or off, connect or disconnect the power cord provided with the switch. A power cord is supplied with the switch.

Note

For the power requirements, refer to the “Power Specifications” on page 53.

30
