Page 10

1

Installation

1.

Standortwahl: Wählen Sie einen Aufstellungsort für den Wireless



Ethernet Adapter. Normalerweise ist das Zentrum Ihrer geplanten



Zelle für die drahtlose Datenübertragung, am besten mit freier



Sicht auf alle drahtlosen Geräte, der beste Standort.

2.

Wählen Sie für den Wireless Ethernet Adapter den Platz mit



dem besten Empfang aus. Normalerweise ist die Leistung umso



besser, je höher die Antenne aufgestellt ist.

3.

Positionieren Sie die Antennen wie gewünscht. Ein besserer



Empfang wird erreicht, wenn Sie die Antenne entlang

Deutsch

unterschiedlichen Achsen positionieren. Sie können z. B.

versuchen, die Antennen ca. 45 bis 90 Grad voneinander





entfernt auszurichten. (Die Antennen senden entlang der



Toroidalebene Signale aus, daher ist der Empfang besser, wenn



sie entlang unterschiedlichen Achsen positioniert werden.)

4.

Schließen Sie im Ethernet-Adapter-Modus für eine kabellose



Kommunikation mit dem Access Point das Ethernet-Kabel an



die RJ-45-Buchse des Geräts an.

5.

Schließen Sie im Access Point-Modus das Ethernet-Kabel an.



Der SMC2671W kann mit Hilfe eines UTP-Ethernet-Kabels der



Kategorie 3, 4 oder 5 und eines RJ-45-Anschlusses über ein



Ethernet-Gerät (z. B. Hub oder Switch) mit einem Ethernet-



Netzwerk verbunden werden.

6.

Schließen Sie das Netzkabel an. Verbinden Sie das Kabel des



Netzteils mit der Strombuchse an der Rückseite des Geräts.



Achtung: Es darf nur das mit dem SMC2671W gelieferte Netzteil



verwendet werden.

7.Prüfen Sie die LEDs auf der Vorderseite, um festzustellen, ob der Adapter eingeschaltet und sein Status ordnungsgemäß ist.

8.Prüfen Sie, ob der Computer im Subnetz 192.168.2.x arbeitet. Gehen Sie hierfür wie folgt vor:

a)Klicken Sie auf die Schaltfläche [Start], klicken Sie auf [Run] (Ausführen) und geben Sie command ein.

b)Drücken Sie [OK]. Es erscheint ein schwarzer Bildschirm mit einer Eingabeaufforderung.

c)Geben Sie ipconfig ein und drücken Sie die Eingabetaste.

d)Prüfen Sie, ob die IP-Adresse 192.168.2.x ist (x steht für

2 ~ 24 oder 26 ~ 254). Wenn dies der Fall ist, können Sie den SMC2671W mit dem EZ Installationsassistenten von SMC EZ konfigurieren. Wenn die IP-Adresse völlig anders ist, finden Sie im Abschnitt über die Konfiguration der IP-Adresse auf Seite 25 des Handbuchs weitere Hinweise.

Deutsch

17
