Requisitos do Sistema

Um programa de navegação, como o Microsoft Internet

Explorer 5.5 ou superior, instalado num PC nas suas instalações, para configurar o Adaptador Ethernet Sem Fios.

Unidade de CD-ROM.

Uma tomada de corrente CA.

Um adaptador de rede por cabo ou sem fios.

Uma porta RJ-45 (UTP) disponível num hub ou switch Ethernet.

Protocolo de rede TCP/IP instalado em cada PC que necessite de aceder à Internet.

Português

Hardware

O Adaptador Ethernet Sem Fios de 11 Mbps EZ ConnectTM suporta ligações half-duplex de 1, 2, 5,5 e 11 Mbps a redes Ethernet. Este dispositivo é totalmente compatível com ligações de rede sem fios DSSS CSMA/CA de 2,4 GHz, conforme definido nas especificações IEEE 802.11b. Pode ser conectado, através de uma ligação RJ-45, a dispositivos como o Nintendo GameCube, Microsoft Xbox e Sony PlayStation II, bem como a dispositivos integrados, preparados para Ethernet. Também pode funcionar como um Ponto de Acesso IEEE 802.11b ou como um Extensor de Alcance.

O Adaptador Ethernet Sem Fios de 11 Mbps EZ ConnectTM possui três tipos de indicadores LED. Consulte a figura (vista frontal do Adaptador) e a tabela em baixo, que descreve o significado do estado actual de cada LED.

LED

Estado

Função







Alimentação

Ligado (Vermelho)

Alimentação ligada.

(PWR)

Desligado

Alimentação desligada.







LAN sem fios

Intermitente

A ligação LAN sem fios

(TX/RX)

(Verde)

está a transmitir ou





a receber.







LAN

Intermitente

Intermitente: A ligação

(LINK/ACT)

(Verde)

LAN por cabo está





a transmitir ou





a receber.



Ligado

Ligado (Verde):



(Verde)

O dispositivo está





ligado a 100 Mbps.



Desligado

Desligado (Laranja):



(Laranja)

O dispositivo está





ligado a 10 Mbps





activos.







Português

73

74

Image 38
