1

Installatie

1.

Selecteer de locatie: Kies een locatie voor uw Wireless Ethernet



Adapter. Gewoonlijk vormt het midden van uw draadloze



dekkingsgebied, zo mogelijk binnen zichtafstand van alle



draadloze apparaten, de beste locatie.

2.

Plaats de Wireless Ethernet Adapter zodanig dat u een maximaal



dekkingsbereik hebt. Normaal gesproken geldt, hoe hoger u de



antenne plaatst, hoe beter de werking.

3.

Zet de antennes in de gewenste stand: Kies verschillende



hoeken voor de antennes om een zo effectief mogelijk bereik te

Nederlands

realiseren. Probeer de hoeken van de antennes bijvoorbeeld zo’n

45 tot 90 graden van elkaar af te laten wijken. (De antennes





verzenden signalen langs het toroïdale vlak en bieden zo een



effectiever bereik bij positionering onder verschillende hoeken.)

4.

Als het apparaat wordt gebruikt als Ethernet-adapter, sluit u de



Ethernet-kabel aan op de RJ-45-aansluiting als het apparaat



draadloos zal communiceren met een toegangspunt.

5.

Als het apparaat wordt gebruikt als toegangspunt sluit u de



Ethernet-kabel aan. De SMC2671W kan dan via een bedrade



verbinding worden aangesloten op een Ethernet-netwerk met



behulp van een Ethernet-apparaat, zoals een hub of een switch



met een UTP Ethernet-kabel van categorie 3, 4 of 5 en een



RJ-45-connector.

6.

Sluit de voedingskabel aan: Sluit de kabel van de



voedingsadapter aan op de voedingsaansluiting op het



achterpaneel. Waarschuwing: gebruik alleen de voedingsadapter



die is meegeleverd met de SMC2671W.

7.Controleer de LED’s aan de voorkant van het apparaat om te controleren of de adapter correct is ingeschakeld en de status in orde is.

8.Controleer of uw computer werkt in het subnet 192.168.2.x. Dit doet u als volgt:

a)Klik op de knop [Start], klik op [Run] (Uitvoeren) en typ command.

b)Klik op [OK]. Er wordt nu een zwarte opdrachtprompt weergegeven.

c)Typ ipconfig en druk op Enter.

d)Controleer of uw IP-adres 192.168.2.x is (waarbij x tussen 2 en 24 of tussen 26 en 254 ligt). Als dat het geval is, kunt u nu de EZ Installation Wizard van SMC gebruiken om uw SMC2671W te configureren. Als uw IP-adres heel anders is, raadpleegt u de sectie Uw IP-adres configureren van de handleiding op pagina 25 voor verdere instructies.

Nederlands

67
